Invertor hibrid trifazat pentru centrale fotovoltaice, sisteme de alimentare de rezervă. Proiectat pentru diferite tipuri de baterii reîncărcabile (plumb Acid, plumb Carbon, LiFePO4).
Invertoarele Voltronic reprezintă performanțe ridicate, fiabilitate și preț rezonabil.
Vânzare pe credit, livrare în Moldova.
Specificații:
Phaze 3
input DC
Max PV power (W) 12000
Rated voltage (V) 120-430VDC
Max. input voltage (V) 450VDC
Start-up voltage (V) 130VDC
MPPT track 3
Max. input current (A) 16
Max. input strings number 1
Bat. Data
Bat. Voltage 48VDC
Max. Solar Charging Carent 180A
Max. AC Charging Carent 180A
Max. Charging Carent 180A
Output AC
Rated output power (W) 9000
Nominal out Voltage (V) 220/230/240VAC(P-N) 380/400/415VAC(P-P)
Max. output current (A) 13 per phase
Input AC Data
Nominal in Voltage 90-280V
Maximal Current (A) 30
Rated grid voltage 3/N/PE
Efficiency
Max.efficiency 93%
EU efficiency 93%
Dimension
(DxWxH) mm 588*260*655
Weight (Kg) 38
Operating ambient temperature range -25~60 gr C
Ingress protection Ip41
Cooling concept Natural convection
Features
DC connection MC4 connector
Display LCD
AC connection Quick connection plug
Communication USB/RS232 and dry contact
Paralel mode 3 units
